30 MHz Dual Channel Function / Arbitrary Waveform Generator

Kostenlose Lieferung

14-bit, 150 MSa/s, 16k point arbitrary waveform generator
Two independent channels with individual output On/Off buttons
Convenient channel copy, track and combine functions
Synchronize the phase of both channels with the push of a button
Low-jitter square wave generation for simulating reliable clock signals, generating triggers, or validating serial data buses
AM/DSB-AM/ASK/FM/FSK/PM/PSK/PWM modulation functions
Variable DC offset and adjustable duty cycle
Internal/external triggering
Gate and burst mode
196 built-in predefined arbitrary waveforms
Built-in frequency counter
Harmonics generator function
LAN, USB device port (USBTMC-compliant), and front panel USB host port
GPIB connectivity with optional USB-to-GPIB adapter
PC software provided for arbitrary waveform editing
Short circuit output protection

Detaillierte Informationen

Weitere Produkte in der Kategorie

(exkl. MwSt.)	€ 848,75
Preis inkl. MwSt.	€ 1 018,50
Stk.
Verfügbarkeit des Produkts	Auf Anfrage
Produktnummer	BK_BK4054B

Garantie 36 Monate

Produktseite des Hersteller

Detailbeschreibung
Videos und Dateien zum Herunterladen

Detailbeschreibung 30 MHz Dual Channel Function / Arbitrary Waveform Generator

The 4050B Series Dual Channel Function/Arbitrary Waveform Generators are capable of generating stable and precise sine, square, triangle, pulse, and arbitrary waveforms. With an easy-to-read color display and intuitive user interface with numeric keypad, these instruments offer plenty of features including linear/logarithmic sweep, built-in counter, extensive modulation and triggering capabilities, a continuously variable DC offset, and a high performance 14-bit, 150 MSa/s arbitrary waveform generator. CH1 and CH2 outputs can both be varied from 0 to 10 Vpp into 50 ohms (up to 20 Vpp into open circuit).
