Rigol DNA804 Vector Network Analyzer, 5 kHz - 4.5 GHz, 2 ports

Kostenlose Lieferung

Frequency Range: 5 kHz to 4,5 GHz
Number of Ports: 2
Frequency resolution: 1 Hz
Max. output power: 10 dBm
High dynamic range: 125 dB (typ.)
Trace noise: 0.005 dBrms
IF BW: 1 Hz to 3 MHz

More detailed specifications and dimensions of available models are specified in data sheet. Detaillierte Informationen

Weitere Produkte in der Kategorie

(exkl. MwSt.)	€ 2 618,03
Preis inkl. MwSt.	€ 3 141,64
Stk.
Verfügbarkeit des Produkts	Auf Anfrage
Produktnummer	RIG_DNA804

Zusammenhängende Produkte

Produktseite des Hersteller

Detailbeschreibung
Videos und Dateien zum Herunterladen

Detailbeschreibung Rigol DNA804 Vector Network Analyzer, 5 kHz - 4.5 GHz, 2 ports

The DNA800 Series is an ultra-portable entry-level vector network analyzer featuring a true two-port architecture and frequency coverage from 5 kHz to 14 GHz. In a compact form factor, it delivers comprehensive S-parameter and impedance measurements. With a typical 125 dB dynamic range, 1 Hz to 3 MHz IF bandwidth, and 0.005 dB rms trace noise, it is well suited for testing passive components, filters, and matching networks. A 7-inch multi-touch display, HDMI output, and full SCPI remote control with compatibility for mainstream command sets simplify automated testing in both laboratory and production environments.

Compact in Size. Powerful in Performance.

Every model weighs just 1.9 kg. Pack it into the RIGOL Ultra-Portable Instrument Bag and take professional measurements wherever your work takes you.

Standard USB Type-C PD Power

Supports the standard USB Power Delivery (PD) protocol via the Type-C interface. Power the instrument with a power bank for business travel and field testing.

Dual Ports. Wide Frequency Coverage.

Frequency coverage from 5 kHz to 14 GHz. A true two-port architecture supports full S-parameter (S11 / S12 / S21 / S22) and impedance measurements. Two units can be cascaded for expanded port configurations.

Complete VNA Functionality

All models support port extension, fixture de-embedding, Pass/Fail testing, and DTF/TDA cable fault and impedance analysis. Multiple data formats and multi-window display improve measurement efficiency.

New Electronic Calibration Kits

The new ECAL300/400 Series electronic calibration kits simplify two-port calibration with plug-and-calibrate convenience. Precision mechanical calibration kits are also supported to meet different application requirements.

Standard USB, LAN and HDMI Connectivity

USB and LAN interfaces support remote communication with the standard SCPI command set. An HDMI output enables connection to an external display for enhanced viewing.

WebControl

Access and control the instrument through a web browser using its IP address, no PC software installation required. Ideal for remote operation and SCPI command debugging.
