Einführung Datenlogger Sefram Datenlogger 6 Channel Handheld Data Acquisition Solution. Carrying case and 2 Pt100/1000 channels included

6 Channel Handheld Data Acquisition Solution. Carrying case and 2 Pt100/1000 channels included

Kostenlose Lieferung

6 Channel Handheld Data Acquisition Solution. Carrying case and 2 Pt100/1000 channels included


  • 6 analogue isolated channels
  • Universal input
  •
  • DC, AC+DC RMS voltage measurement
  •
  • Frequency, counter
  • Temperature: thermocouple, Pt100/Pt1000 (2 separate channels)
  •
  • Network and power analysis function (up to 400Hz) with trigger on parameters
  •
  • Inrush current measurement
  •
  • PWM measurement
  • 16 logical channels
  • 14-bit resolution
  • 10" TFT panoramic LCD touch screen
  • 1 Ms/s sampling rate
  • 100 kHz bandwidth
  • 64 GB internal hard disk
  • 32 Mword memory
  • Interfaces: 2 x USB, Ethernet, WiFi (option)
  • Lithium-ion battery
  • 110mm Thermal printer module (option)
  • IEC 1010 CAT III 600V
  • Detaillierte Informationen

(exkl. MwSt.) € 6 596,00
Preis inkl. MwSt. € 7 915,20
 Stk.
Verfügbarkeit des Produkts Auf Anfrage
Produktnummer BK_DAS60

Garantie 12 Monate

Detailbeschreibung 6 Channel Handheld Data Acquisition Solution. Carrying case and 2 Pt100/1000 channels included

The new Data Acquisition Solution DAS60 is part of the family of standalone, portable, battery operated instruments dedicated to high-speed recording. With 6 isolated channels, 16 logical inputs, 2 Pt100/Pt1000 inputs, more than 9 hours autonomy, a 64GB memory, the DAS60 is the ideal tool for R&D, diagnostic and maintenance. With a special function of Power Analysis, you can record all your parameters on a Single-Phase and Three-Phase network up to 400Hz. The remote control and the download of memorized data is very convenient using one of the interfaces provided: Ethernet, USB, WiFi (option). To view and manage your data, we propose several license-free software that can be downloaded from our website and that will match your needs. Available with printer option.
